Products / Embedded System Computing / Computer on Module / MicroSOM

MicroDev 2.0 Carrier Board

General-purpose miniature carrier board based on MicroGEA STM32MP1 & MicroGEA MX6ULL module. Available with CAN Bus and LTE interfaces

MicroGEA STM32MP1 & MicroGEA MX 6ULL Module compliant
Wide 7 to 40 Vdc single power supply
1 x microSD
1 x RS485
1 x RS232 for OS Console
1 x 10/100 Ethernet interface
WiFi + BT (option)

We also provide additional features to our finished products if requested.
Contact us, for customized product package!
Get A Quote

General-purpose miniature carrier board based on MicroGEA STM32MP1 & MicroGEA MX6ULL module. Available with CAN Bus and LTE interfaces

Specifications

Order Info

Downloads

Related Products

name	code	description	availability
MicroDev 2.0 BASIC+LCD+CAN	0027T211020000	MicroDev 2.0 BASIC+LCD+CAN (MicroGEA MX6ULL 800MHz, 512MB DDR3, 512MB NAND, Ethernet, 2xRS232, 1XUSB, 1xSD, Industrial, LCD i/f, CAN)	MP
MicroDev 2.0 3G/CAN board	0027T210021510	MicroDev 2.0 3G/CAN board (MicroGEA MX6ULL 800MHz, 512MB DDR3, 512MB NAND, Ethernet, 2xRS232, 1XUSB, 1xSD, Industrial, CAN, WiFi+BT, UMTS/3G UG96 Global, Exp. Connector)	MP
MicroDev 2.0 LTE/CAN board	0027T210021810	MicroDev 2.0 LTE/CAN board (MicroGEA MX6ULL 800MHz, 512MB DDR3, 512MB NAND, Ethernet, 2xRS232, 1XUSB, 1xSD, Industrial, CAN, WiFi+BT, LTE EG95 EMEA, Exp. Connector)	MP
MicroDev 2.0 LTE/RS485 board	0027T210011810	MicroDev 2.0 LTE/RS485 board (MicroGEA MX6ULL 800MHz, 512MB DDR3, 512MB NAND, Ethernet, 2xRS232, 1XUSB, 1xSD, Industrial, RS485, WiFi+BT, LTE EG95 EMEA, Exp. Connector)	MP
MicroDev 2.0 GPRS/CAN board	0027T210021710	MicroDev 2.0 GPRS/CAN board (MicroGEA MX6ULL 800MHz, 512MB DDR3, 512MB NAND, Ethernet, 2xRS232, 1XUSB, 1xSD, Industrial, CAN, WiFi+BT, GPRS M95 Global, Exp. Connector)	MP
MicroDev 2.0 GPRS/RS485 board	0027T210011710	MicroDev 2.0 GPRS/RS485 board (MicroGEA MX6ULL 800MHz, 512MB DDR3, 512MB NAND, Ethernet, 2xRS232, 1XUSB, 1xSD, Industrial, RS485, WiFi+BT, GPRS M95 Global, Exp. Connector)	MP

Back to list

T: +31-252-278800
info@portwell.eu

This website uses cookies to offer you an optimal website experience. These include cookies that are necessary for the operation of the site and for the control of our commercial corporate goals (Mandatory / Technical Cookies), as well as those that are only used for anonymous statistical purposes, for comfort settings or to display personalized content (Marketing Cookies). You can decide which category you want to allow. Please note that based on your settings, not all functions of the page may be available. For further information regarding cookies please see our Data Protection Declaration and regarding us on the Imprint.

Mandatory/Technical

These cookies are needed for a smooth operation of our website.

Name	Purpose	Lifetime	Type	Provider
CookieConsent	Saves your consent to using cookies.	1 year	HTML	Website
fe_typo_user	Assigns your browser to a session on the server.	session	HTTP	Website

Marketing

With the help of these cookies we strive to improve our offer for our users. By means of anonymized data of website users we can optimize the user flow. This enables us to improve ads and website content.

Name	Purpose	Lifetime	Type	Provider
_pk_id	Used to store a few details about the user such as the unique visitor ID.	13 months	HTML	Matomo
_pk_ref	Used to store the attribution information, the referrer initially used to visit the website.	6 months	HTML	Matomo
_pk_ses	Short lived cookie used to temporarily store data for the visit.	30 minutes	HTML	Matomo
_pk_cvar	Short lived cookie used to temporarily store data for the visit.	30 minutes	HTML	Matomo
_pk_hsr	Short lived cookie used to temporarily store data for the visit.	30 minutes	HTML	Matomo
_ga	Used to distinguish users.	2 years	HTML	Google
_gat	Used to throttle request rate.	1 day	HTML	Google
_gid	Used to distinguish users.	1 day	HTML	Google
_ga_--container-id--	Persists session state.	2 years	HTML	Google
_gac_--property-id--	Contains campaign related information for the user. If you have linked your Google Analytics and Google Ads accounts, Google Ads website conversion tags will read this cookie unless you opt-out.	3 months	HTML	Google
_gcl_au	Used by Google AdSense to experiment with advertisement efficiency.	3 months	HTML	Google
AMP_TOKEN	Contains a token that can be used to retrieve a Client ID from AMP Client ID service. Other possible values indicate opt-out, inflight request or an error retrieving a Client ID from AMP Client ID service.	1 year	HTML	Google
_dc_gtm_--property-id--	Used by DoubleClick (Google Tag Manager) to help identify the visitors by either age, gender or interests.	2 years	HTML	Google
MUID	Used as unique user identifier. The cookie allows user tracking across many Microsoft domains.	1 year	HTML	Bing
MUIDB	Saves anonymous user data from multiple website visits on multiple sites to test advertisement efficiency.	1 year	HTML	Bing
_fbp	Stores the unique visitor ID.	28 days	HTML	facebook
facebookPixel	If JavaScript is not enabled, this pixel initiates a connection to facebook.	none	Pixel	facebook

Analytics

Name	Purpose	Lifetime	Type	Provider
_ga	Used to distinguish users.	2 years	HTML	Google
_gat	Used to throttle request rate.	1 day	HTML	Google
_gid	Used to distinguish users.	1 day	HTML	Google
_ga_--container-id--	Persists session state.	2 years	HTML	Google
_gac_--property-id--	Contains campaign related information for the user. If you have linked your Google Analytics and Google Ads accounts, Google Ads website conversion tags will read this cookie unless you opt-out.	3 months	HTML	Google
_gcl_au	Used by Google AdSense to experiment with advertisement efficiency.	3 months	HTML	Google
AMP_TOKEN	Contains a token that can be used to retrieve a Client ID from AMP Client ID service. Other possible values indicate opt-out, inflight request or an error retrieving a Client ID from AMP Client ID service.	1 year	HTML	Google
_dc_gtm_--property-id--	Used by DoubleClick (Google Tag Manager) to help identify the visitors by either age, gender or interests.	2 years	HTML	Google

Technology:	ARM
Operating Temperature:	Industrial temperature available
Power Requirement:	Wide 7 to 40 Vdc single power supply
OS Support:	Linux
USB:	1 x USB Type A
Network:	1 x 10/100 Ethernet interface
Chipset:	SoC (System-On-Chip)
Format:	Micro SOM
Dimensions:	Tiny Size: 80 x 50 mm
