RS4U-B641-P&E

Embedded rugged fan-less system with Intel Apollo Lake SoC processor besed Mini-ITX board

Latest Apollo Lake platform
4K codec encode & decode ability
50G dynamic shock/vibration support
9-32V wide range DC in
API function control
CFEX support with SPI ROM inside

We also provide additional features to our finished products if requested.
Contact us, for customized product package!
Get A Quote

Compact System for Industrial Automation & Control Targeting, Power & Energy, based on the Apollo Lake N3350 processor, 2GB x1 DDR3L, CFEX 2GB w/SPI & 64GB SATA SSD.

Specifications

Order Info

Downloads

name	code	description	availability
RS4U-B641-P&E - SI	tbd	The builds on Intel	MP
RS4U-B641-P&E-OEM	tbd	Embedded rugged and fan-less system based carrier boards with COMe Apollo Lake N3350, 2GB DDR3L installed, CFEX 2GB w/SPI ROM & 64GB SATA SSD, 2xGbE, VGA, HDMI, DP, 4xUSB 3.0, COM port, 9-32V DC in.	MP

Back to list

T: +31-252-278800
info@portwell.eu

This website uses cookies to offer you an optimal website experience. These include cookies that are necessary for the operation of the site and for the control of our commercial corporate goals (Mandatory / Technical Cookies), as well as those that are only used for anonymous statistical purposes, for comfort settings or to display personalized content (Marketing Cookies). You can decide which category you want to allow. Please note that based on your settings, not all functions of the page may be available. For further information regarding cookies please see our Data Protection Declaration and regarding us on the Imprint.

Mandatory/Technical

These cookies are needed for a smooth operation of our website.

Name	Purpose	Lifetime	Type	Provider
CookieConsent	Saves your consent to using cookies.	1 year	HTML	Website
fe_typo_user	Assigns your browser to a session on the server.	session	HTTP	Website

Marketing

With the help of these cookies we strive to improve our offer for our users. By means of anonymized data of website users we can optimize the user flow. This enables us to improve ads and website content.

Name	Purpose	Lifetime	Type	Provider
_pk_id	Used to store a few details about the user such as the unique visitor ID.	13 months	HTML	Matomo
_pk_ref	Used to store the attribution information, the referrer initially used to visit the website.	6 months	HTML	Matomo
_pk_ses	Short lived cookie used to temporarily store data for the visit.	30 minutes	HTML	Matomo
_pk_cvar	Short lived cookie used to temporarily store data for the visit.	30 minutes	HTML	Matomo
_pk_hsr	Short lived cookie used to temporarily store data for the visit.	30 minutes	HTML	Matomo
_ga	Used to distinguish users.	2 years	HTML	Google
_gat	Used to throttle request rate.	1 day	HTML	Google
_gid	Used to distinguish users.	1 day	HTML	Google
_ga_--container-id--	Persists session state.	2 years	HTML	Google
_gac_--property-id--	Contains campaign related information for the user. If you have linked your Google Analytics and Google Ads accounts, Google Ads website conversion tags will read this cookie unless you opt-out.	3 months	HTML	Google
_gcl_au	Used by Google AdSense to experiment with advertisement efficiency.	3 months	HTML	Google
AMP_TOKEN	Contains a token that can be used to retrieve a Client ID from AMP Client ID service. Other possible values indicate opt-out, inflight request or an error retrieving a Client ID from AMP Client ID service.	1 year	HTML	Google
_dc_gtm_--property-id--	Used by DoubleClick (Google Tag Manager) to help identify the visitors by either age, gender or interests.	2 years	HTML	Google
MUID	Used as unique user identifier. The cookie allows user tracking across many Microsoft domains.	1 year	HTML	Bing
MUIDB	Saves anonymous user data from multiple website visits on multiple sites to test advertisement efficiency.	1 year	HTML	Bing
_fbp	Stores the unique visitor ID.	28 days	HTML	facebook
facebookPixel	If JavaScript is not enabled, this pixel initiates a connection to facebook.	none	Pixel	facebook

Analytics

Name	Purpose	Lifetime	Type	Provider
_ga	Used to distinguish users.	2 years	HTML	Google
_gat	Used to throttle request rate.	1 day	HTML	Google
_gid	Used to distinguish users.	1 day	HTML	Google
_ga_--container-id--	Persists session state.	2 years	HTML	Google
_gac_--property-id--	Contains campaign related information for the user. If you have linked your Google Analytics and Google Ads accounts, Google Ads website conversion tags will read this cookie unless you opt-out.	3 months	HTML	Google
_gcl_au	Used by Google AdSense to experiment with advertisement efficiency.	3 months	HTML	Google
AMP_TOKEN	Contains a token that can be used to retrieve a Client ID from AMP Client ID service. Other possible values indicate opt-out, inflight request or an error retrieving a Client ID from AMP Client ID service.	1 year	HTML	Google
_dc_gtm_--property-id--	Used by DoubleClick (Google Tag Manager) to help identify the visitors by either age, gender or interests.	2 years	HTML	Google

CPU:	Intel® Celeron® Processor N3350 (2 x 1.10 GHz, 2 MB L2, 6 W)
Technology:	x86
Format:	Mini-ITX
Chipset:	SoC (System-On-Chip)
DRAM:	Up to 16GB DDR3L Dual 204 pin SO-DIMM socket
Display Interface:	1x VGA, 1x HDMI, 1x DP
Storage:	1x 2.5" HDD/SSD
Network:	2x Gigabit Ethernet
Serial Interface:	1 x COM (1x RS-232/42/485, 1x RS-232)
USB:	4x USB3.0 (Rear)
Audio:	Line-in/ Line-out
Operating Temperature:	-20~50'C
Storage Temperature:	-20~50'C
