LYNX-812E

Compact, fan-less embedded system powered by the Intel® Amston Lake X7213RE / X7433RE

Slim Fanless System with Intel Amston Lake X7213RE (2-core) / X7433RE (4-core), TDP 9W
Up to 32GB LPDDR5 4800 MT/s memory (default 8GB)
Up to 256GB On-board eMMC & M.2 SATA SSD support
Dual Intel® I226IT 2.5GbE LAN ports
2x USB 3.2 Gen1 x2, 1x USB Type-C Gen2 x1 (with DP ALT mode)
Expansion: M.2 for WiFi, 4G/5G with SIM & Hailo-8 AI Accelerator
Certified: CE, FCC Class A, EN62368-1

We also provide additional features to our finished products if requested.
Contact us, for customized product package!
Get A Quote

A rugged, compact embedded system powered by Intel® Amston Lake processors with rich I/O and wireless expansion. Supports up to 32GB LPDDR5 memory, dual 2.5GbE, and TPM 2.0 security, ideal for industrial automation, edge computing, and AI inference at the edge.

Specifications

CPU:	Intel Atom® x7433RE Processor (4 / 3.4 GHz, 6 MB, 9 W) Intel Atom® x7213RE Processor (2 / 3.4 GHz, 6 MB, 9 W)
Processor:	Intel Amston Lake X7213RE, 2 cores, TDP 9W Intel Amston Lake X7433RE, 4 cores, TDP 9W
Chipset:	Intel® SoC
Memory:	LPDDR5 4800 MT/s Non-ECC Memory chips up to 32GB (default: 8GB)
Storage:	1 x M.2 M key 2242 socket (For M.2 2242 M key SATA SSD) On board eMMC up to 256GB (default: 128GB)
Expansion:	1 x M.2 E Key 2230 socket (For M.2 WiFi module) 1 x M.2 B Key 3042/3052 socket with dual Micro SIM socket For M.2 4G/5G cellular module, Hailo-8 AI Accelerator module is adopted
Ethernet:	2 x Intel® I226IT 2.5Gb ports
USB:	2 x USB 3.2 Gen 1×1 ports 1 x USB Type C Gen 2×1
Console:	2 x RS-232/RS-422/RS-485
Display Feature:	1 x HDMI® 1.4a port 1 x USB Type C port with DP ALT mode
Dimension:	120mm(W) x 74mm(H) x 120mm(D)
Power:	DC 12V~30V
Mounting:	Wall mounting / DIN Rail mounting
Vibration:	5Grms/10~500Hz, IEC 60068-2-6
Shock:	50G, 11msec, IEC 60068-2-27
IP Protection:	IP30
Operating Temperature:	-40°C ~ 70°C
Relative Humidity:	40°C, 95% RH, non-condensing
Storage Temperature:	-40°C ~ 85°C
Weight:	1 KG
OS Support:	Windows 10 / Windows 11 / Linux
Certificates:	CE, FCC Class A, EN62368-1
